Introduction

Glaucoma, a progressive optic neuropathy, is characterized by a loss of retinal ganglion cells and their axons as well as tissue remodeling that affects both the optic nerve head and the retina.4 Clinically, this leads to a visible excavation of the optic nerve and to thinning of the nerve fiber layer of the retina. The patients suffer a progressive loss of the visual field.5 Increased intraocular pressure (IOP) is an important risk factor for the development of primary open angle glaucoma. But others risk factors such as impaired ocular blood flow and oxidative stress also play an important role in the pathogenesis of glaucoma.

Oxygen and oxidative stress

The oxygen molecule is minimally reactive.6 This is because the oxygen molecule has two unpaired electrons, each of which are located in a different (π*) antibonding orbitals. These two electrons rotate about their own axis in the same direction and thereby have the same or parallel spins. This is the ground state of oxygen which is the most stable state of oxygen. If another atom or molecule would donate two electrons to the oxygen (oxygen gets reduced), both of these electrons would have to be of antiparallel spin, to oxygen’s electrons, so as to fit in to the vacant spaces in the π* orbitals.7 This makes it difficult for the oxygen molecule to accept a pair of electrons from another atomic or molecular orbital, since according to Pauli’s principle, a pair of electrons in other atomic or molecular orbitals would have opposite spins. This “spin restriction” forces oxygen to accept its electrons one at a time, explaining why the oxygen molecule reacts sluggishly with many non-radicals.8

Oxygen is the most important oxidizing agent in metabolic reactions that lead to the release of energy from the oxidation of various organic molecules. In the respiratory chain (electron transport chain), which takes place in the area of the inner membrane of the mitochondria, the oxygen molecule functions as a terminal electron acceptor.9 However, the metabolism of the oxygen molecule does not always work correctly. This malfunction has the consequence that reactive oxygen species (ROS = reactive forms of oxygen species) are created.10,11

In healthy individuals there is an almost balanced relationship between the production of ROS and the production of antioxidants. If the balance is slightly tipped in favour of the production of ROS there’s a need for antioxidant defense and repair as the body can adapt to a certain degree of oxidative stress by enhancing its defense mechanisms. ROS are derived from both endogenous sources (peroxisomes, mitochondria, endoplasmic reticulum, phagocytic cells etc.) as well as from exogenous sources (alcohol, tobacco smoke, pollution, heavy metals, transition metals, industrial solvents, pesticides, certain drugs including paracetamol and radiation).12

When the balance, is in favor of the production of ROS then the condition known as oxidative stress is caused (Figure 1).13 Oxidative stress causes damage to various cellular macromolecules such as proteins, lipids, sugar residues or DNA; This can potentially lead to cellular growth arrest, cell-related loss of quality, or even cell death.14,15 Oxidative stress has been reported to be involved in several diseases such as diabetes mellitus, cardiovascular diseases such as atherosclerosis, respiratory diseases such as asthma, in various cancers and in glaucoma.13,16–18

Figure 1. In physiological conditions is a balanced relationship between the production of ROS and the production of antioxidants.

When the balance is in favor of the production of ROS the condition called oxidative stress results. ROS, reactive oxygen species (taken from 4).

Blood flow in glaucoma

Most glaucoma patients have impaired blood flow in various tissues of the eye, including the optic nerve, retina, iris and choroid.19 In normal pressure glaucoma, the reduction in blood flow is even more pronounced than in high pressure glaucoma. Interestingly, in glaucoma patients, a reduced blood flow is also observed in the capillaries of the fingernail folds.20 This suggests that the reduced blood flow is not solely due to an increase in IOP or to glaucoma damage. Rather, there is obviously a primary vascular dysregulation.

Basically, we have two extremes in our population (Figure 2): on the one hand we have patients with high blood pressure, high body mass index, often diabetes type II. They often have a so-called metabolic syndrome (high resistance to insulin). They have a high risk for arteriosclerosis and also a higher probability to develop an increase in IOP and therefore to develop glaucoma, particularly high tension glaucoma.

If we consider the other extreme in the population, we see people with the Flammer Syndrome (FS) with low blood pressure, low body mass index, often cold extremities. There are often physically and intellectually very active. People with FS have a so called primary vascular dysregulation syndrome (PVD), which often interferes with autoregulation of ocular perfusion.2,21 For this reason they also have a higher chance to develop glaucoma (particularly normal tension glaucoma (NTG)). This explains why NTG occurs more often in females than in males, in Japanese than in Americans, NTG progresses until a certain age and then often stabilizes.

Figure 2. Spectrum of our population.

Whereas on one extreme side of the spectrum of a population we find people with the Flammer Syndrome (low blood pressure, low body mass index, low blood sugar levels), on the other extreme we find those with the metabolic syndrome (high blood pressure, high body mass index, high blood sugar levels). Adapted from Fischer, Mozaffarieh 2018.22

Primary Vascular dysregulation (Flammer Syndrome)

Systemic dysregulation can be primary or secondary of nature.23 Secondary vascular dysregulation results from other diseases e.g., autoimmune diseases. Secondary vascular dysregulation occurs in the context of diseases in which cells other than the vascular endothelial cells (somewhere in the body) produce an additional amount of endothelin.3 Typical examples of diseases are MS, arthritis, polyarthritis or AIDS. This leads to a more or less constant reduction of ocular blood flow. It does however, not interfere with autoregulation. Therefore, small vessel disease (SVD) is only a minor risk factor for glaucomatous neuropathy (GON), but a risk factor for some optic nerve head atrophy or even infarction. With primary vascular dysregulation – also known as FS – there is an inborn tendency to react differently to different stimuli such as cold or emotional stress.18 In daily practice, people with FS are easy to recognize. These people complain about cold hands and feet (even during the summer months), have a reduced feeling of thirst, need more time to fall asleep, have an altered sense of smell (Figure 3) and often notice a change in sensitivity to drugs and more often have a migraine (www.flammersyndrome.ch).

Figure 3. People with Flammer Syndrome can generally smell better than other individuals.

Adapted from Mozaffarieh et al. 2010.24

Patients with FS suffer from a disorder of the autoregulation of their blood circulation, which leads to fluctuations in the IOP or blood pressure values and thus to repeated mild reperfusion damage.16,21 This explains why these patients are at an increased risk of developing GON.

In people with FS pulse waves in retinal vessels propagate faster than in people without FS.25 This indicates that the rigidity of their retinal vessels in FS is higher despite their anatomically normal appearance. In addition, spatial irregularity of retinal vessels is increased in people with FS, the neurovascular coupling is decreased, and autoregulation of the ocular blood flow is disturbed.26 The disturbance of the autoregulation of ocular blood flow depicts the causal relationship between FS and glaucomatous damage. People with FS also have higher retinal venous pressures as measured by means of ophthalmodynamometry and a higher chance of retinal vein occlusions and central serous chorioretinopathy.27–29

At times there’s some confusion between the terminology in the use of FS and Raynaud disease.30 FS is not the same as a Raynaud disease. Raynaud disease is an autoimmune disease and therefore belongs to the group of SVD. Patients with Raynaud disease do not have a higher risk for glaucoma.

Ocular blood flow disturbances and oxidative stress

Vascular dysregulation impairs the autoregulation of ocular blood flow.21 Physiological or pathologically increased fluctuations in the perfusion pressure therefore also lead to corresponding fluctuations in the ocular blood flow.31,32 Repeated mild reperfusion lesions induced by fluctuations in ocular blood flow are part of the actual mechanism causing the damage that leads to GON. Thus, fluctuations in blood flow represent a significantly more serious risk factor for the development of GON than a stable decrease in ocular blood flow. In reperfusion, the blood flow of the optic nerve head, which is particularly subject to fluctuations, increases, and the production of free radicals increases significantly. The area of the optic nerve head is characterized by high energy consumption as the axons there do not have myelin sheaths and therefore contain a large number of mitochondria that produce free radicals as a result of the mild reperfusion damage (especially the superoxide anion).33,34

Chemical reactions leading to neuronal cell death

The mitochondria play an important role in reperfusion phenomena.35 Mitochondria are the cell’s power plants. It is here, where glucose and fat are burned. During this process, the electrons migrate through the respiratory chain from one energy level to the next. In reduced perfusion, this electron transport is partly impaired so the electrons “stack up”. As soon as blood flow normalizes again, the electron flow normalizes but because the electrons were previously “stacked up” one single electron may go astray. As soon as this electron encounters an oxygen molecule nearby a free radical (namely the superoxide anion) is formed.15,36 An increased formation of free radicals also impairs the reuptake of glutamate. This results in an increase in the extracellular glutamate concentration and thus the phenomenon of excitotoxicity. In the event of excitotoxicity, nitrogen monoxide (NO) is formed increasingly.33,34 The latter is also produced when the astrocytes in the retina or optic nerve head are activated. NO is a small, lipophilic molecule that can easily diffuse into neighboring cells, for example into the axons of the optic nerve head. If, as a result of reperfusion, superoxide anion is also present in high concentration, the very harmful peroxynitrite molecule is formed.16 Both superoxide anions and peroxynitrite are hydrophilic and therefore cannot diffuse out of the cell through the intact cell membrane.37 Superoxide anions and peroxynitrite can, however, diffuse intra-axonally to the retina and to the lateral geniculate body where they cause cell apoptosis.

Discussion

Glaucoma is a multifactorial disease in which a variety of risk factors such as increased IOP, blood flow disturbances, and oxidative stress play an important role. These factors are interrelated and are involved in a process that ends in damage to the optic nerve and ganglion cells. The disturbance of the ocular blood flow leads to the production of free radicals. These trigger oxidative stress, provided they are not switched off by antioxidant protective mechanisms.

This new interpretation of the pathogenesis of glaucoma is likely to lead to the development of new therapies for the prevention of glaucoma in the future and is also relevant for the early diagnosis of glaucoma. Ocular blood flow and oxidative stress are two crucial parameters in the pathogenesis of this serious eye disease.
